Super-capacitor Tester
CT-4008-5V10mA Super-capacitor Test System, characterized with 0.05% FS accuracy and down to μA capability, enables users to perform DCIR tests, dQ/dV and other basic tests on three-electrode system. It mainly focuses on battery research & development institutions and universities. |
Please enter valid quantity.
Product Description
Super-capacitor Test System | Material Research
|
Super-capacitor Tester
CT-4008-5V10mA/6A/12A
|
CT-4008-5V10mA Super-capacitor Test System, characterized with 0.05% FS
accuracy and down to μA capability, enables users to perform DCIR tests,
dQ/dV and other basic tests on three-electrode system. It mainly focuses
on battery research & development institutions and universities.
|
Learn more about 5V12A Super-capacitor Test
|
|
|
|
"Super" function on the tray BTS 4000
|
It's so easy to test the battery capacitance equipping with the purpose-made tray.
|
|
|
|
|
|
10Hz/ 100Hz
Data
Acquisition
Frequency
|
|
|
|
|
|
500ms
Min. Pulse
Width
|
|
|
|
|
Three-Electrode
System
Test
|
|
|
|
|
Charge &
Discharge
Rate
|
|
|
|
|
μA
Current Unit
|
|
|
|
|
dQ/dV
Curve
|
|
|
|
|
DCIR
|
|
|
|
|
0.05%FS
Accuracy
|
|
|
|
|
3 Range
|
|
|
|
|
≤500μ/1ms
Response Time
|
|
|
BTS upper computer integrated temperature test chamber control
|
NEWARE supercapacitor test system realizes integrated operation and collaborative work through BTS upper computer control system, so as to maximize the supercapacitor characteristics and functions.
|
|
|
|
Fission temperature control system
|
It can be perfectly combined with Neware test chambers to jointly complete various types of super capacitor tests.
|
|
|
|
|
dQ/dV
|
dQ/dV differential capacity curve: the peak on the curve indicates that there is a voltage plateau on the charge and discharge curve, and different peaks represent different electrochemical reactions.
|
|
Conditions Switches
|
Battery testing steps need to be estimated for several conditions according to different operations during testing applications; Conditions switches meet requirements for multi-exits programming types. “And””or” logic operation, “≥”, ”≤”, ”=” comparatively calculate; Time duration ”t”, can achieve control requirements for special testing. Every step supports 5 condition switches; Support multi-exits, go to any steps, achieve more flexible process control.
|
|
Segment-Record Conditions
|
Data record settings for voltage, current and time are supported; 3 segment-record conditions can be set for each step; Every segment can be set: ΔT, ΔV and ΔI .
|
|
Control peripheral equipment by communication
|
BTS Server come true the peripheral equipment (Battery tester & Automation) communication control via switch.
|
|
Super-capacitor testing
|
The unit of Q is Coulomb, 1 Coulomb = 1A * 1s = 1As; 1Ah = 3600 As(Amp Second); Work voltage U = Charge upper limited voltage - Discharge bottom limited voltage; Working voltage can be set and the EDLC coulomb could be calculated automatically by the software.
|
|
|
Size & Weight
|
Purpose-made tray for 5v10mA super capacitor test
|
|
|
Small but powerful.
|
Net weight of middle machine:2.5kg; Net weight of single equipment: About 5kg
|
|
|
The Mode Of Networking
|
|
|
Accessories
Promoting creativity
|
|
|
More about CT-4008-5V10mA capacity tester……
|
Learn more about specification.
|
|
